Electrical Testing & Commissioning Course
Duration: 2 Year (6 Months Crash Course)
Total Fee: ₹ 24000/-
Eligibility: Minimum ITI / Diploma / Degree passed with age limit above 20 years.
With a total fee of Rs 24000, this is a tow-year course with a six-month crash course with two to three terms of payment plan available. With the current industrial situation, there's a lot of opportunity in this course.
| Courses / Trade | Admission Fee | 1st Instalment | 2nd Instalment | 3rd Instalment | Total Fee |
|---|---|---|---|---|---|
| Electrical Testing & Commissioning Course | 1000 | 10000 | 10000 | 3000 | 24000 |
PURPOSE:
Industrial Electrical Testing & Commissioning perform a variety of functions related to electrical controls, equipment, and wiring in an industrial plant or worksite. Their work may involve testing, troubleshooting, installation, and repair of the electrical components.
The main difference is the setting. Rather than plying their trade in homes or offices, these tradesmen work in factories and plants. Consequently, they may work on larger, higher-capacity equipment.
COURSE CONTENT:
1. TRANSFORMERS:
Specification: Power and distribution transformers as per BIS standards.
Installation: Location, site, selection, foundation details (like bolts size numbers, etc.)
Commissioning: Test: Following tests as per national & international standard, volt ratio test earth resistance, oil strength, Buchoiz & others relays, tap changing gear, fan& pumps, insulation test, impulse test, polarizing index, load & temperature rise test.
Specific Tests: Determination of performance curves like efficiency, regulation etc. and determination of mechanical stress under normal conditions.
2. SYNCHRONOUS MACHINES:
Specification: As per BIS standards.
Commissioning Test: Insulation, Resistance measurement of armature & field windings, waveform & telephone interference test, line charging capacitance.
Performance Test: Various test to estimate the performance of generator operations, slip test, maximum lagging current, maximum reluctance power test, Sudden short circuit tests, transient & sub transient parameters, measurements of sequence impedances, capacitive reactance and separation of losses, temperature rise test and retardation test.
3. INDUCTION MOTORS:
Specification for different types of motors, Duty, I.P. protection.
Installation: Location of the motors (including the foundation details) & its control apparatus, shaft & alignment for various coupling, fitting of pulleys & coupling, drying of windings.
Commissioning Test: Mechanical test for alignment, air gap symmetry, tests for bearings, vibrations & balancing.
Electrical Test: Insulation test, earth resistance, high voltage test, starting up, failure to speed up to take the load, type of test, routine test, factory test and site test (in accordance with ISI code).
Speed Test: Performance & temperature raise tests, stray load losses, shaft alignment and re-rating and special duty capability.
4. SWITCH GEAR & PROTECTIVE DEVICES:
Standards, types, specifications, installation, commissioning tests, maintenance schedule type & routine tests.
5. The Pre-Commissioning & Preliminary Phase.
6. The Testing & Commissioning Agenda.
7. Earthing and Testing.
8. Switch-gear and Connection Testing.
9. Protection Testing in Practice.
10. Group Session Practical's.
11. Safety.
